comparison of product parameters
| Input Voltage(V) | AC100-277V | IP Rating | IP65 |
| Lamp Luminous Efficiency(lm/w) | 130 | Application | Garden |
| Certification | LVD, ETL, Emc | Light Distribution Shape | 120Degree |
| Lifespan (Hours) | 50000 | Warranty(Year) | 5-Year |
| Color Temperature(CCT) | 3000K4000K6500K | Color Rendering Index(Ra) | 80 |
| Installation | Wall Mount, Surface Mounted | Support Dimmer | No |
| Material | Aluminum | Working Time (hours) | 50000 |
| Control Method | Touch | Lighting solutions service | Agi32 Layout |
| Special Feature | High Bright | Light Source | LED |
| Led chip | SMD | Beam Angle(°) | 60/90/120 |
| Lamp Luminous Flux(lm) | 6500-52000 | Place of Origin | Guangdong, China |
| CRI (Ra>) | 80 | Product Weight(kg) | 5 |
Complete Product Performance Advantages
Ultra High Luminous Efficiency: Equipped with top-tier high-brightness Uniled LED chips, reaching an industry-leading luminous efficiency of 130lm/W, which generates brighter uniform illumination while cutting 60%+ electricity consumption compared to traditional halogen & metal halide floodlights.
Precise Optical Control System: Adopts high-transmittance UV-stabilized optical PC lens, realizing targeted light output without stray light waste; eliminates glare to deliver soft, even lighting for large-area coverage.
Powerful Full-Range Heat Dissipation: Housing made of high thermal conductivity ADC12 die-cast aluminum, matched with thick high-conductivity aluminum substrate; integrated ribbed back heat sink structure forms vertical air convection channels to rapidly export chip operating heat.
Extreme Temperature Adaptability: Frost-proof & heat-resistant integrated design, supports stable normal operation in extreme environments ranging from -40°C cold frost zones to 60°C high-temperature tropical areas; no performance drop under long-term alternating hot & cold conditions.
Stable Constant Current Drive Power Supply: Compatible with multiple well-known brand driver solutions, featuring over-voltage, over-current, short-circuit and surge lightning protection functions; avoids flicker, voltage fluctuation interference and sudden lamp failure.
Anti-Corrosion & Wear-Resistant Shell: Matte anti-oxidation aluminum alloy surface treatment, resists acid rain, salt fog and outdoor oxidation; robust structure prevents scratches, impact and mechanical wear during installation & long-term outdoor exposure.
Flexible Adjustable Installation Bracket: Bevel angle adjustable metal mounting bracket design, allows 180-degree free rotation to customize lighting projection angle; supports wall-mounted, ground-mounted, pole-mounted and overhead installation for diverse scene demands.
Anti-Yellowing Internal Optical Components: Built-in high-temperature resistant nano reflective sheet and UV-proof PC lens, both maintain original transparency after years of outdoor UV radiation; no yellowing, darkening or light output reduction.
Tempered Safety Light Cover: High-hardness thick tempered glass front cover, anti-impact, anti-cracking and dust-proof; blocks external hard object impacts without breaking to protect internal LED chips.
Professional Waterproof Performance
Certified IP65 Ingress Protection Standard
IP6X Dustproof: Fully enclosed lamp cavity completely blocks fine dust, sand, industrial ash and pollen. No dust accumulation on LED beads, reflective sheet or circuit board to avoid light loss and short circuit risk. Ideal for construction sites, factories and mining yards.
IPX5 Waterproof: Multi-circle thickened food-grade silicone waterproof gasket tightly fits between tempered glass cover and aluminum housing. Resists high-pressure water jet flushing from any angle, heavy continuous rain, splashing water and melted snow immersion. Zero water penetration inside the fixture.
Multi-Layer Sealed Anti-Leakage Design
Independent waterproof silicone ring for light surface + secondary sealed wiring inlet. Double waterproof barrier prevents rainwater seepage from lamp face and power cord joint, the two most common leakage positions of cheap floodlights.
Integrated one-piece casting housing without assembly gaps, eliminating hidden water leakage slits on lamp body frame.
All-Weather Anti-Corrosion Waterproof Matching Materials
UV-stable silicone sealing ring won't harden, crack or shrink after long-term outdoor sun & rain exposure. Cheap rubber gaskets will turn brittle in 1–2 years and lose waterproof function, but our silicone gasket maintains tight sealing for over 5 years.
Anti-rust coated metal screw fasteners fix the glass cover; no rust expansion to break the sealing gap in rainy or coastal salt fog areas.
Built-In Lightning Surge Protection Matched with Waterproof Structure
The fully sealed waterproof cavity isolates internal driver and circuit board from humid air. Together with 4KV anti-surge lightning circuit, it avoids lamp burnout caused by thunderstorm humidity + grid voltage surge.
Outdoor Scene Waterproof Adaptability
Work stably under heavy monsoon rain, winter snow melting, coastal salt spray and humid tropical climates. No fogging inside the glass cover, no bead short-circuit, no driver failure due to moisture.
High-Efficiency Heat Dissipation System
ADC12 Die-Cast Aluminum Heat Sink Housing
High thermal conductivity ADC12 aluminum alloy raw material, far better heat transfer than thin plastic or low-grade recycled aluminum used by low-cost competitors. Rapidly transfer heat generated by LED chips out of the lamp body.
Integrated vertical ribbed heat sink on the lamp back, forming natural vertical air convection channels. Hot air rises and dissipates quickly, cold air continuously flows in to cool the fixture actively without extra cooling fans (zero fan failure risk).
High Thermal Conductivity Aluminum Substrate for LED Beads
Thickened high-purity aluminum PCB substrate directly carries LED chips, quickly conducts concentrated heat of lamp beads to the aluminum housing heat sink. Avoid local overheating of single bead which causes fast light decay and bead burnout.
Extreme Temperature Resistance Supported by Excellent Heat Dissipation
Perfect heat control keeps the chip working temperature below 75°C even under continuous full-power lighting in 60°C high-temperature summer outdoor environment.
Wide operating temperature range: -40°C ~ +60°C. Heat sink avoids heat accumulation in hot zones, and solid aluminum structure prevents frost crack in cold northern areas.
Heat Dissipation Reduces Light Decay & Extends Service Life
Excessive heat is the top cause of LED lumen depreciation and early scrapping. Our full cooling system limits lumen attenuation to only 5% after 10,000 working hours, total light loss less than 18% over full 50,000-hour lifespan.
No heat accumulation to damage the internal driver power supply; the constant current driver works at low temperature to maintain stable output and avoid flicker or sudden lamp dead.
Auxiliary Heat Optimization Structural Design
Hollow gap between internal reflective sheet and aluminum housing reserves extra heat circulation space, preventing heat trapping inside the light cavity.
Bevel mounting bracket keeps a gap between lamp back and wall/mount pole, reserving air flow space for heat sink, will not block heat dissipation when wall-mounted.
