Do Exit Sign Emergency Lights Combine Signage and Backup Lighting?

When entering a shopping mall, hotel, warehouse, or office building, you have surely noticed the green or red "EXIT" signs overhead. But have you ever observed that some of these signs feature two small, adjustable lamp heads attached to them? This type of product is known as an "Exit Sign Emergency Light Combo." Many purchasers and contractors often ask: can an exit sign and emergency lighting really be combined into a single unit? The answer is yes-in fact, such products are quite common in markets across North America, the Middle East, and Australia. Let's take a closer look at their structure, operating principles, and how to select the right model.

Simply put, it integrates two functions into one housing:

Exit Sign Function: Displays the word "EXIT" or a "running man" icon to indicate the escape route.

Emergency Lighting Function: In the event of a power failure, a pair of adjustable lamp heads illuminate the floor and pathways near the exit.

Both functions share the same enclosure, battery system, and charging circuitry. In the industry, these are commonly referred to as an "exit/emergency combo" or "combo exit sign."

The operating logic is straightforward and generally consists of three stages:

During normal power conditions: The unit is connected to the mains (AC power). This powers the exit sign panel (typically LED-based) while simultaneously charging the internal battery, keeping it fully charged and ready for use.

During a power outage: The internal circuitry detects the loss of mains power and automatically switches to battery power-no manual intervention is required.

In emergency mode: The exit sign panel remains illuminated, and the lamp heads turn on. This typically provides at least 90 minutes of runtime, with some models capable of lasting up to 3 hours.

One important detail often overlooked is that the exit sign panel and the lamp heads share the same battery capacity. Consequently, higher-wattage lamp heads will reduce the total runtime, a trade-off that should be carefully considered when selecting a model.

Compared to the approach of using a standalone exit sign paired with a separate emergency light, combination units offer several clear advantages:

Space-saving: They require only a single connection point, resulting in fewer openings in ceilings or walls.

Reduced wiring costs: A single wiring connection completes the setup, lowering labor costs.

Neater appearance: They avoid the cluttered look that occurs when two separate units are installed side-by-side.

Simplified inventory management: For distributors, a single model covers two types of requirements, reducing stock-holding pressure.

Centralized maintenance: With one battery and a single testing point, routine inspections are more efficient.

For small-to-medium-sized projects-especially those with tight schedules or limited budgets-these advantages translate directly into cost savings.

Naturally, these units are not a universal solution; there are a few scenarios that clients should be aware of:

Limited illumination range: The light heads typically have a lower power output, making them suitable for illuminating the area immediately in front of an exit door, but not for providing emergency lighting for large corridors or open spaces.

Positioning constrained by the exit sign: Exit signs must be installed directly above an exit, which may not necessarily be the optimal location for emergency lighting.

"All-or-nothing" risk: If the battery degrades, both the exit sign and the emergency light will be affected.

Unsuitable for certain environments: High-ceiling spaces (such as warehouses or gymnasiums) generally require dedicated, high-bay emergency lighting.

Therefore, a more sound approach is to use combination units as the baseline configuration for exits, while supplementing other areas with additional emergency lighting.

These combination units are well-suited for the following areas:

Above entrances/exits to stairwells and emergency exit doors.

At the ends of corridors and around corners.

Along evacuation routes on hotel guest floors or in office buildings.

In small retail shops, restaurants, and classrooms.

Near the entrances and exits of parking garages.

They are typically installed approximately 2 meters above the door, ensuring the sign remains unobstructed and the light heads are oriented toward the evacuation path.

Purchasing and installing the equipment is not the end of the process; the greatest risk for emergency equipment is failing to illuminate when it is needed most. Recommended maintenance routine:

Monthly: Press the test button to ensure both the exit sign and the light head(s) illuminate correctly; hold for approximately 30 seconds.
Annually: Conduct a full-discharge test to verify that the battery runtime meets the required standards.

Ongoing monitoring: Observe the indicator lights (e.g., check if the charging indicator remains steadily lit) and address any irregularities promptly.

Battery replacement: Typically required every 3–5 years, depending on the battery type.

Maintaining accurate records is also essential, as fire safety inspections in many jurisdictions require the presentation of a testing logbook.

Returning to the initial question: Can exit signs and emergency lighting be combined? Yes-in fact, this is a highly practical solution for exit areas. Its primary value lies in using a single unit to both "indicate the way" and "illuminate the path," thereby saving installation space and construction costs.

However, it is important to recognize the limitations: while combined units address basic requirements near an exit, additional standalone emergency lights are still necessary for broader corridor or passageway illumination. When selecting equipment, focus on key factors-battery type, runtime, power capacity, and product certification-to ensure a reliable choice.
