How Microwave Sensing Works
Microwave sensing uses high-frequency electromagnetic radiation to detect moving objects. It is temperature-insensitive and more sensitive than ordinary infrared sensing. When persons or vehicles approach the monitoring area, the light fixture glows at 100% brightness; when they leave, it dims or goes into standby. This triggering system eliminates manual energy waste and is ideal for intermittent operations like night construction and warehouse inspection.
Complex-environment reliability
Emergency power is available for this light, which operates from -40°C to 45°C. It may illuminate for 1.5 hours after a power outage. The microwave detecting module resists rain, snow, and dust, and its 360° beam angle eliminates blind areas. Its high-voltage adaptability (100-480VAC) lets it adapt to varied power grid settings in different countries without voltage stabilizing equipment.
| Wattage | 40W |
| Luminous Flux | 5,200lm |
| Replacement | HPS 120W |
| Light Source | SMD LED |
| Luminous Efficacy | ≥130lm/w |
| Options | Standard; wih connector(Used for series connection between lamps and lamps); with emergency power(After the power failure, make sure the lamp can still work for 1.5h) |
| Operation Temp | -40 to +45℃ |
| CCT | 5000K |
| CRI | 80+ |
| Life Span | 50,000 hours at 25℃ |
| Voltage | 100-277VAC/50-60Hz 200-480VAC/50-60Hz available |
| Driver | Internal Power Supply |
| Dimming | Standard: Not dimmable; Dimmable optional |
| Sensor | Standard: No sensor; Microwave sensor optional |
| Remote Control | Standard: No remote; Remote control optional |
| Beam Angle | 360° |
| Lamp Base | Hook Install |
| PF | >0.95 |
| Warranty | 5Years |
Energy conservation and long-term operation benefits
The 130lm/W luminous efficacy exceeds high-pressure sodium lamps. Light output is 5200lm at 40W. Microwave detection decreases energy waste, saving over 60%. Its 50,000-hour lifespan and 5-year warranty decrease maintenance, making it ideal for long-term outdoor projects. Options include microwave sensing and non-sensing versions for cost-effective and versatile use.
Application scenario core value
Microwave sensing speeds safety response in mines, building sites, and emergency rescue operations. Manual operation in the dark and power loss from forgetting to turn off the lights are avoided with automatic lighting. In addition, the detecting function and high color rendering index (CRI 80+) ensure operation precision and fulfill transient lighting conditions' intelligent needs.
For more details about our offerings, please contact us at bwzm18@ledbenweilighting.com.
