Temporary illumination for building sites in the past may have included a few lengths of strung wire and a few hanging pigtails here and there, possibly held by screws. This kind of construction won't be accepted any longer because it poses a danger of electrical shock due to frayed or fractured wires. Temporary lighting strings are simpler to install, manage, take down, and store in 2001 because they are not only naturally more robust and designed specifically for secure, stress-free hanging.
The majority of goods are made to endure the rough handling, strains, and stresses that may result from working with different professions that genuinely don't care about the health of your lights. Modern stringers typically have sockets spaced 10 feet apart along a length of wire, along with plastic cages that can be easily replaced by snapping off for simple cage replacement and opening without the need for tools. Each socket has an incorporated eyelet that makes it easy to hang the fixture and, as a result, support the wire at the appropriate distances.
Support for interim cabling at building sites is specifically addressed in Article 305 of the 1999 National Electrical Code (NEC), which states that "cable assemblies and flexible cord shall be held in position at intervals that guarantee there will be protection from physical harm." Temporary lighting stringers are produced by manufacturers in accordance with at least one of the following standards: UL Rating (UL Standard 1088, temporary lighting strings), OSHA Regulations 1910 and 1926, and NEC Article 305. Temporary lights must have guards to prevent unintended interaction with the lamp (unless the bulb is deeply hidden) and heavy-duty electric cables with secure connectors and insulation, per OSHA Lighting Requirements (1915.92). Temporary lights cannot be suspended by their cables per OSHA Standard 1926.405 unless the cords and lights are made specifically for that purpose. Additionally, cables must be kept out of any walking-working area and any other area where they could be damaged, according to OSHA rules. Temporary lighting stringers or streamers must be organized to prevent overloading and visible noncurrent-carrying metal components must be correctly grounded in order for temporary lights to comply with OSHA.
Every branch circuit must have overcurrent safety with a capacity no greater than the cable being used. The items below are illustrative and do not reflect the entire product line from the company. The molded cable version of the McGill String-O-Lights family of temporary lighting systems, which are all UL-Listed, has a PVC hanger that encircles the socket and cable, and the commercial duty Flat-Wire version, which complies with OSHA and NEC regulations and has an enclosed conductor that resists impact, oil, and abrasion. The safety yellow impact-resistant plastic enclosures can hold up to 200-watt lights. The molded temporary lighting units from Bergen Industries, model number GL-100, are UL listed, NEC approved, and OSHA compliant. They have molded cords, high-impact yellow plastic cages, copper socket shells that are covered in injected plastic, and two-way eyelets on top of the sockets that can be used to run guide wires. Protection - Daniel Woodhead Yellow string lights are made to endure the heat produced by aftermarket (non-standard) hot service bulbs. A round heavy-duty wire and a socket with stress-relief ridges help prevent the jacket from pulling away from the socket and revealing the conductors in the UL-listed, NEC-compliant, and OSHA-compliant product. In addition to grounded metal lamp guards, which offer some crush protection and are appropriate for places where there is a risk of the light being struck, basket choices include yellow plastic, clear polycarbonate (to shield the lamp against particulate accumulation and impact), and clear polycarbonate.
Electronic Safety Products by Ericson Construct-O-Lite 2-Wire Light-Duty Molded Stringlights are made for uses that call for quick set-up, tear-down, and installation. They have a jacketed wire and a fully threaded screwshell to guarantee correct contact. The stringers are offered in 50-foot and 100-foot lengths, with customizable spacing if requested, and are UL listed as well as OSHA and NEC compliant. Firm for Engineered Goods Both interior and exterior use is possible with Deluxe CordLights thanks to their weather-resistant light sockets, heavy-duty nonmetallic bulb cages, and heavy-duty round cable. The lights, which are designated for 150-watt lamps, are resistant to dust, grime, chemical vapors, saline spray, and other corrosive elements. They also satisfy UL, NEC, and OSHA requirements. Duraline prefabricated Heavy-Duty Lighting Streamers have heavy-duty molded rubber structure and crushproof, watertight receptacles, making them well-suited to harsh interior and outdoor settings.
The NEC-compliant streamers can accommodate incandescent or fluorescent lights as well as a steel guard with a vinyl coating or a crushproof transparent lexan guard. According to the maker, they are completely recoverable for repeated use, waterproof to three feet of water, and usable in mud regions. Lamps Both a rough service incandescent lamp (clear or frosted) and a surge-proof lamp are available from Philips Lighting. The rough service incandescent lamp has an exceptionally strong filament that, according to the company, makes it suitable for installations where shocks, bumps, and vibrations frequently occur. Both come in a wide variety of wattages.
The Sylvania Rough Service XL provides 5,000 hours of average estimated bulb life and is designed to endure high-amplitude/low-frequency shocks, bumping, banging, hard handling, and other characteristics of rugged use. They come in frost variants and 60, 75, and 100 watt models. Options for high-intensity discharge (HID) are gaining popularity. For 400-watt metal halide lights suspended from I-bolts or other supports, manufacturers are offering UL-Listed HID fixtures. For places where the mounting height is greater than 15 feet, the lights could produce a significant amount of light per unit. McGill's 400-Watt HID Temporary Lighting fixture is equipped with a hook and an inbound power cable so it can be connected or inserted in and is specifically designed to illuminate work locations.
The tough formed and forged steel wire shield on Cooper Lighting's new Lumark Steeler Worklight, which is UL-listed, is painted safety yellow polyester paint. Accessories include electrical cables with and without plugs, fixture clips, and loops. The FELDMANS produce web material for businesses and write on a variety of subjects for magazines, trade organizations, building product makers, and other businesses. They can be contacted at www.benweilighting.com, Or you can directly contact Amelia at bwzm18@ledbenweilighting.com.
