comparison of product parameters
|
Input Voltage(V) |
AC 165-265V |
IP Rating |
IP20 |
|
Lamp Luminous Efficiency(lm/w) |
100 |
Color Temperature(CCT) |
2700K-6500K |
|
Support Dimmer |
No |
LED Light Source |
Smd2835 |
|
Warranty(Year) |
2-Year |
Lamp Body Material |
Aluminum |
|
Application |
Home Office |
Design Style |
Modern |
|
Feature |
Easy Installation, High Brightness |
Lighting solutions service |
Lighting And Circuitry Design |
|
Light Source |
LED |
Place of Origin |
China |
|
Product Type |
LED Panel Light |
Installation |
Recessed / Ceiling Mounted |
| Power | 18W |
Color Temperature |
2700K-6500K |
Performance & Optical Excellence
High-Efficacy Light Engine: Powered by premium SMD2835 LED chips with an optical lens refraction design, achieving 100–120 lm/W standard efficacy-saving over 50% energy compared to traditional fluorescent fixtures.
Advanced Glare Control: Precision-engineered diffuser delivers UGR<19 (Unified Glare Rating), eliminating harsh glare and eye strain for comfortable, screen-friendly workspaces.
Flicker-Free Constant Current Driver: Adopts the latest efficient constant current driver for instant start-up, zero flicker, and no audible noise-ensuring visual comfort and compliance with modern workplace standards.
High-Transparency Optical Mask: Oil- and dirt-resistant PMMA light guide plate provides uniform light distribution, high light transmittance, and easy-clean maintenance even in high-traffic commercial zones.
Premium Color Rendering: CRI >80 (optional CRI 90/95) ensures vivid, natural color reproduction, ideal for retail displays and hospitality settings.
Lifespan & Lumen Maintenance
50,000-Hour Rated Life: Certified for 50,000 hours of continuous operation-3–5× longer than ordinary spliced-frame panels and 8–10× longer than traditional fluorescent lamps.
Superior Lumen Maintenance (L70/L80): Engineered to retain ≥70% of initial luminous flux after 50,000 hours (L70B50), with premium options achieving L80 maintenance-preventing gradual dimming, uneven illumination, and color shift.
Thermal Management for Slow Light Decay: High-thermal-conductivity 6063 aluminum alloy frame efficiently dissipates heat, protecting LED chips from thermal degradation and ensuring stable performance across -40°C to 50°C operating temperatures.
Loss Resistance & Structural Durability
Seamless Welded 6063 Aluminum Frame: Aviation-grade one-piece integral welding eliminates structural gaps, loose connections, and light leakage-maintaining a flat, integrated profile even under long-term thermal expansion and ceiling pressure.
Anti-Deformation & Corrosion Resistance: Painted aluminum frame is hard, high-temperature resistant, rust-proof, and moisture-proof-preventing warping, cracking, or structural fatigue in demanding commercial environments.
Reinforced Backplate & Sealed Assembly: Thickened high-strength backplate and sealed design prevent dust, oil fume, and fine particulate ingress-preserving luminous efficiency and reducing cleaning/replacement frequency.
Low Total Cost of Ownership: Flicker-free driver and robust construction minimize maintenance labor, replacement frequency, and energy waste-delivering predictable operational savings over a 5–10 year service window.
