comparison of product parameters
|
Application |
Warehouse |
Input Voltage(V) |
100-277VAC |
|
Lamp Luminous Efficiency(lm/w) |
140, 150, 170 |
IP Rating |
IP65 |
|
Color Temperature(CCT) |
5000K (Daylight) |
Lifespan (Hours) |
50000 |
|
Warranty(Year) |
5-Year |
Color Rendering Index(Ra) |
70 |
|
Support Dimmer |
No |
Control Method |
Switch Control |
|
Light Source |
LED |
Led chip |
Smd2835 |
|
Lamp Body Material |
Aluminum alloy |
Feature |
High Brightness, Easy Installation, Durable, Eco-Friendly, Water Resistant |
|
Lighting solutions service |
Lighting And Circuitry Design |
Place of Origin |
Guangdong, China |
|
Lamp Luminous Flux(lm) |
28000, 30000,34000 |
Product Weight(kg) |
2 |
|
Working Temperature(℃) |
-40-40 |
Luminous Efficacy |
140LM/W, 150LM/W, 170LM/W |
|
Working Time (hours) |
50000 |
CRI (Ra>) |
70 |
Core LED Chip & Luminous Performance
Adopts premium Epistar / Lumileds 2835 SMD LED chips, industry-leading luminous efficiency up to 165lm/W, far higher than conventional industrial lighting lamps
Uniform light output without dark spots, glare-free optical design, effectively reduce visual fatigue for long-hour working environments
High color rendering index (CRI>80 optional CRI90), restore true object color, perfect for logistics sorting, manufacturing workshop, retail supermarket lighting
Wide color temperature range available: 3000K warm white / 4000K neutral white / 5000K / 6000K cool white to match diverse site lighting demands
Die-Cast Aluminum Housing & Heat Dissipation System
Full die-cast aluminum alloy housing with integrated fin-shaped radiator structure, ultra-large heat dissipation contact area for fast heat convection
Hollow ventilation slot design on lamp body side, accelerate air circulation to take away heat generated by LED chips and power supply
One-piece molding aluminum shell with strong structural rigidity, anti-impact, anti-deformation, suitable for harsh factory and workshop environments
Black anti-corrosion electrostatic spray surface treatment, resist oxidation, dust, oil fume and chemical mist erosion, keep stable heat dissipation efficiency for years
High Transmittance Optical Lens & Adjustable Beam Angle
High-transmittance anti-UV PC optical lens, light transmittance over 92%, minimal light loss during light refraction
Three optional beam angles: 60° / 90° / 120°, flexible to match different ceiling heights and lighting coverage requirements
60° narrow beam: for high ceiling over 10m, centralized high-lumen illumination for tall warehouse racks
90° medium beam: universal for standard factory, supermarket, gymnasium 6-10m ceiling
120° wide beam: for low ceiling workshop, large-area open space uniform lighting
Impact-resistant PC lens, not easy to crack or yellow after long-term exposure to light, maintain stable light output
How To Cooperate With Us?
Because of our own facilities, we have complete control over the production process and the quality of our goods, which makes us very pleased. We are committed to giving our clients the greatest price since we are manufacturers rather than just brokers. We encourage clients to evaluate our samples first since we are certain that the cost and quality of our items are transparent. Our dedication to excellence and client happiness motivates us to consistently provide superior products.
Our address
3rd Floor, 5th Building, Hebei Industrial Park, Hualian Community, Longhua District, Shenzhen, China
