comparison of product parameters
|
Application |
Sports Stadiums |
Light Source |
LED |
|
Input Voltage(V) |
100-277V |
IP Rating |
IP65 |
|
Lamp Luminous Efficiency(lm/w) |
150 |
Lifespan (Hours) |
50000 |
|
Color Temperature(CCT) |
3000-6500K |
Color Rendering Index(Ra) |
80 |
|
Lamp Body Material |
Aluminum |
Warranty(Year) |
5-Year |
|
Support Dimmer |
No |
Lighting solutions service |
Lighting And Circuitry Design |
|
Base Type |
other |
Working Temperature(℃) |
-20-50 |
|
Place of Origin |
Guangdong, China |
Beam Angle(°) |
10°/ 30°/45°/ 60° |
|
Lamp Luminous Flux(lm) |
75000-225000 |
Item Type |
Led Stadium Light |
|
Product Name |
High Brightness Outdoor Ip65 Waterproof Aluminum Smd Led Stadium Light |
Optional Power |
500W 1000W 1500W |
|
Keyword |
Led Stadium Light/high-pole lamp |
Light Source |
SMD3030/3535 |
|
Lamp Bead Amount |
688/2376/2604 |
Usage |
Parking Lot,Stadium |
✅ Superior Lighting Performance
Equipped with high-quality 3030 / 3535 LED lamp beads adopting ultra-thick double gold wire packaging technology, higher luminous efficiency, stronger luminous intensity and excellent color rendering consistency.
Modular splicable design: single module, dual-module, triple-module assembly optional, flexible power configuration to meet diversified lighting requirement of different project scenarios.
Precise optical design optional, multiple beam angle selections available to avoid light waste, achieve uniform light distribution and effectively reduce glare.
Constant current driver built inside, stable output voltage & current, effectively prevent light flicker under unstable power supply environment.
High power factor (PF＞0.95), low harmonic distortion, energy-saving efficiency far exceeds traditional metal halide lamps and halogen lamps, saving up to 65% electricity cost.
✅ Flexible Installation & Humanized Structure Advantages
Thickened reinforced mounting bracket supports 180° free angle adjustment, lockable positioning, convenient to adjust lighting direction according to actual illumination demands.
Independent sun visor equipped for each module, effectively block stray light and improve directional lighting effect.
Complete assembly accessories provided, compatible with pole mounting, wall mounting and vertical bracket installation for stadium lighting towers.
Compact modular split structure, easy for container loading, effectively reduce transportation volume and ocean freight cost.
✅ Industrial-Grade Protection Performance
High-standard IP66 waterproof & dustproof rating. Fully sealed lamp structure prevents rainwater, splash water, dust, sand from penetrating into internal components.
High strength tempered transparent lens, anti-oxidation, anti-yellowing, impact resistant, suitable for all kinds of harsh outdoor environment.
Die-cast aluminum alloy housing with anti-corrosion surface spraying treatment, anti-rust, anti-oxidation, adaptable to coastal salty fog, humid, high-temperature working environment.
Built-in multiple protection functions: overvoltage protection, overcurrent protection, surge lightning protection, short circuit protection to avoid lamp damage caused by abnormal grid voltage.
