comparison of product parameters
| Application | Sports Stadiums | Light Source | LED |
| Input Voltage(V) | AC100-305V | IP Rating | IP66 |
| Lamp Luminous Efficiency(lm/w) | 160 | Lifespan (Hours) | 50000 |
| Color Temperature(CCT) | 2700-6500K | Color Rendering Index(Ra) | 70Ra/80Ra |
| Lamp Body Material | Aluminum | Warranty(Year) |
5-Year |
| Support Dimmer | No | Lighting solutions service | Agi32 Layout, Lighting And Circuitry Design, Project Installation |
| Working Temperature(℃) | -25°C + 45°C | Place of Origin | Guangdong, China |
| Beam Angle(°) | 10° 20° 40° 60° asy.50° | Lamp Luminous Flux(lm) | 160,000lm |
| Product Weight(kg) | 28.5 | Power | 1000W |
| Power Factor | 0.97 | IP Rating | IP66 |
| CRI | 70Ra/80Ra | Certificates | CE RoHS |
| Warranty | 5 Years | Input voltage | AC100-305V |
Superior Modular Lighting Performance & Custom Optical Design
Detachable independent light module structure: single module rated 100W, freely assemble 1/2/3/4/5/6 modules to realize 100W–600W flexible power output, adapting to small plazas and large professional sports venues.
Premium high-refractive frosted optical lens for every module, effectively soften light output to eliminate harsh glare and visual fatigue for stadium audiences and field workers.
Multiple fixed beam angle options for customized lighting demands: 10° narrow spotlight for long-distance tower top projection, 20°/40° medium beam for road and yard lighting, 60° wide flood beam for full ground coverage of sports courts.
High-brightness imported SMD LED chips, luminous efficiency reaches 145–160lm/W, 75% energy saving compared with traditional metal halide stadium lamps of equivalent brightness.
Uniform matrix chip layout inside each module, zero dark zones, shadow spots or uneven brightness; ensures consistent illuminance across the entire target lighting surface.
Built-in isolated constant-current driver with wide AC85–305V universal voltage compatibility, stable light output under fluctuating industrial and municipal power grids.
Optional high CRI ≥85 version for venue photography, broadcast and sports match live streaming, accurately restoring object and athlete color details.
Black anti-glare visor hat brim mounted on each module, blocks stray light spillage to avoid light pollution for surrounding residential areas, fully compliant with outdoor municipal lighting standards.
Multi-Dimensional Adjustable Heavy-Duty Mounting Bracket
Double-layer thickened carbon steel reinforced main support bracket, electrostatic anti-rust black coating, high load-bearing capacity to support up to 6 combined modules without deformation.
Dual independent angle adjustment system: each single light module owns a separate locking knob for fine-tuning its individual irradiation angle; the whole lamp bracket features graduated perforated disc for overall large-range angle adjustment (0–90° vertical tilt).
Graduated angle scale marks on the adjustment disc, enables precise repeated positioning during installation, greatly improving construction efficiency for engineering contractors.
U-shaped base mounting bracket with multiple long slotted mounting holes, compatible with pole top, wall side, overhead suspension and ground fixed installation for diversified venue layout.
Anti-loose locking bolt design for all rotating joints, prevents angle shift caused by strong wind, mechanical vibration or long-term gravity extrusion outdoors.
Thickened steel plate structure resists impact and collision during transportation, installation and on-site construction, reducing product damage rate for bulk orders.
3D Aviation Aluminum Heat Dissipation, Ultra-Low Light Decay & Extra Long Service Life
Each module adopts thickened aviation die-cast aluminum alloy housing with vertical three-dimensional fin heat sink, huge heat exchange contact area for fast passive air convection cooling without cooling fans.
High thermal conductivity silica gel tightly bonds LED PCB board and aluminum radiator, instantly exporting core chip operating heat to keep junction temperature low.
Low stable working temperature effectively suppresses chip light attenuation: only ≤22% lumen depreciation after 60,000 hours of continuous operation, far superior to ordinary integrated flood lights with over 50% brightness loss within 25,000 hours.
Rated ultra-long service lifespan up to 60,000 working hours under 24/7 non-stop industrial outdoor operation, 4–6 times longer service life than traditional halogen stadium lamps.
Fanless passive heat dissipation design removes all vulnerable rotating fan components, eliminates common failures including fan burnout, abnormal noise and dust clogging, slashing post-installation maintenance frequency.
All internal driver electronic components adopt high-temperature resistant raw materials, stable continuous operation within ambient temperature range of -40℃ ~ +60℃ without performance degradation.
Split modular heat dissipation structure avoids heat accumulation between multiple stacked modules, each unit dissipates heat independently to extend the full lamp service cycle.
